Model | EX17 | EX27 | EX40 |
Type | Air-cooled,4-cycle,slant single cylinder,OHC,horizontal P.T.O shaft | Air-cooled,5-cycle,slant single cylinder,OHC,horizontal P.T.O shaft | Air-cooled,6-cycle,slant single cylinder,OHC,horizontal P.T.O shaft |
Bore * stroke | 67*48 mm | 75*60 mm | 89*65 mm |
Displacement | 169cc | 265cc | 404cc |
KW(PS)/rpm Continuous output | 2.6(3.5)/3000 2.9(4.0)/3600 | 4.4(6.0)/3000 5.1(7.0)/3600 | 6.3(8.5)/3000 7.0(9.5)/3600 |
Max.output | 5.7hp | 9hp | 14hp |
N·m(Kgf·m)/rpm Max.torque | 11.3(1.15)/2500 | 18.6(1.9)/2500 | 28.5(2.91)/2400 |
Direction of rotation | Counter clockwise as viewed from P.T.O shaft side | Counter clockwise as viewed from P.T.O shaft side | Counter clockwise as viewed from P.T.O shaft side |
Fuel | Automobile unleaded gasoline | Automobile unleaded gasoline | Automobile unleaded gasoline |
Fuel tank capacity | 3.2 L | 5.6 L | 6.8 L |
Lubricant | Automobile oil class SE or higher,SAE 10W-30 | Automobile oil class SE or higher,SAE 10W-30 | Automobile oil class SE or higher,SAE 10W-30 |
Lubricanting Oil capacity | 0.6 | 1 | 1.2 |
Ignition system | Flywheel magneto(solid state) | Flywheel magneto(solid state) | Flywheel magneto(solid state) |
Starting system | Recoil starter | Recoil starter | Recoil starter |
Governor | Centrifugal flyweight type | Centrifugal flyweight type | Centrifugal flyweight type |
Spark Plug | NGK BR6HS | NGK BR6HS | NGK BR6HS |
Carburetor | Float type | Float type | Float type |
Net Weight | 15kg | 21kg | 33kg |
mm Dimensions(L*W*H) | 304*354*335 | 351*420*410 | 389*446*447 |
